Leica Elmar-M 24mm f/3.8 ASPH
%0A84%C2%B0%20/%2074%C2%B0%20/%2053%C2%B0%0A%0A%0AOptical%20design%0A%0A%0A%0ANumber%20of%20lenses/groups%0A8%20/%206%0A%0A%0AFocal%20length%0A24.5%20mm%0A%0A%0APosition%20of%20entrance%20pupil%0A18.7%20mm%20(related%20to%20the%20first...){kind=link}
Write some content that will appear in a modal
Write some content that will appear in a modal
| Angle of view (diagonal, horizontal, vertical) | 84° / 74° / 53° |
| Optical design | |
| Number of lenses/groups | 8 / 6 |
| Focal length | 24.5 mm |
| Position of entrance pupil | 18.7 mm (related to the first lens surface in light direction) |
| Focusing range | 0.7 m to infinity |
| Distance setting | |
| Scales | Combined meter/feet graduation |
| Smallest object field | 615 x 922 mm |
| Largest reproduction ratio | 1:25.6 |
| Aperture | |
| Setting/Function | With click-stops, half values available, manual diaphragm |
| Lowest value | 16 |
| Angle of view (diagonal, horizontal, vertical) | 84° / 74° / 53° |
| Optical design | |
| Number of lenses/groups | 8 / 6 |
| Focal length | 24.5 mm |
| Position of entrance pupil | 18.7 mm (related to the first lens surface in light direction) |
| Focusing range | 0.7 m to infinity |
| Distance setting | |
| Scales | Combined meter/feet graduation |
| Smallest object field | 615 x 922 mm |
| Largest reproduction ratio | 1:25.6 |
| Aperture | |
| Setting/Function | With click-stops, half values available, manual diaphragm |
| Lowest value | 16 |
| Bayonet | Leica M quick-change bayonet with 6 bit lens identification bar code for digital M models |
| Filter mount/Lens hood | Non-rotating, female thread for filters E46, male thread for lens hood, screw-on type lens hood (included in delivery) |
| Dimension and weight | |
| Length | 40.6 / 56.6 mm (without / with lens hood) |
| Largest diameter | approx. 53 mm |
| Weight | 260 g |
Title
Title
Share some content to your customers about your products.
Title
Share some content to your customers about your products.
Choose options
Leica Elmar-M 24mm f/3.8 ASPH
Sale price79.200.000₫
